Polcd ST7789V2 2.4 Tft Display Color 262K TFT LCD Module 48.96mm TFT LCD

Name: Polcd ST7789V2 24 Tft Display Color 262K TFT LCD Module 4896mm TFT LCD
Brand: Polcd
Price: 1 USD

Quality Polcd ST7789V2 2.4 Tft Display Color 262K TFT LCD Module 48.96mm TFT LCD for sale

Brand Name : Polcd

Model Number : P024C117

Certification : RoHS, ISO9001

Place of Origin : Shenzhen, China

MOQ : 1 piece

Price : Please contact us for latest price

Payment Terms : T/T,L/C,Credit card,PayPal,D/A,D/P,Western Union,MoneyGram

Supply Ability : 40,000 PCS per day

Delivery Time : 1-7 working days

Packaging Details : FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm

Size (inch) : 2.4

Resolution : 240*320

Brightness (cd/m²) : 260

Interface : 4 Wire SPI

Driver Ic : ST7789V2

Contact Now

New published Industrial Touch Screen for commercial and industrial use. Our TFT LCD has a 2.4 inch diagonally. The resolution of our tft lcd is 240 * 320. The normal brightness is 260 nits under the test of laboratory. The Interface of this LCD is 4 Wire SPI. We can also customize other types of interfaces and FPCs for you. The ST7789V2 driver IC provides on-chip storage and power system. If your products need to work under a temperature from -20°C to 70°C, then it can meet your needs.

Parameter:

Model	P024C117
Screen Size	2.4 inch
Number of Pixel	240RGB(H)x320(V)
Display area	36.72(H)x48.96(V)mm
Pixel pitch	51(H)x153(V)um
Pins	18 pins
Outline Dimension	42.72x60.26x2.30mm
Pixel arrangement	RGB Vertical Stripe
Display mode	Normally White
Viewing Direction(eye)	12 0'CLOCK
Display Color	262K
Luminance(cd/m2)	260 nit
Contrast Ratio	250:1
Interface	4W SPI
Back-light	LED Side-light type
Drive IC	ST7789V3
Operation Temperature	-20~70℃
Storage Temperature	-30~80℃

FAQ

Q: Can we customize product? What cost will be included?
A: The product can be customized. However, TFT LCD module has different tooling cost which includes FPC, Touch screen, backlight, bezel and so on.

Q: I want make sure some information before order, where should I find the files or datasheet?
A: The easiest way is contact our sales then we will provide any files if you need quickly.

Q: What is your delivery method?
A: EXW Shenzhen by DHL/ UPS/ FedEx/ TNT and any other method you want. Or ship the goods to your forwarder in China mainland and Hong Kong.

Q: What kind of packaging? Will the transport process be damaged?
A: Packed in anti-static bags with foam box to ensure safety in transportation.
